For Beginners - What is CNC Precision Engineering design? What is CAD & CAM?

CNC design refers to the process of creating digital models and instructions for Computer Numerical Control (CNC) machines, which are automated tools used for cutting, milling, drilling, and shaping materials like metal, wood, or plastic. The design process involves creating precise 2D or 3D models of parts or products, which are then translated into machine-readable code (G-code) to guide the CNC machine in manufacturing the physical object.

Key Components of CNC Design are CAD and CAM. CAD stands for Computer-Aided Design and CAM stands for Computer-Aided Manufacturing. Let's see more on what CAD & CAM can do.

CAD is the use of software to create detailed 2D or 3D models of a part or product. It allows designers to visualize, modify, and optimize designs before manufacturing. Examples of CAD software include;

• AutoCAD

• SolidWorks

• Fusion 360

• CATIA.

CAM is the process of using software to convert CAD designs into machine-readable instructions (G-code). It generates toolpaths, which define the movement of the CNC machine's tools to create the part. CAM software also optimizes machining processes, such as tool selection, cutting speed, and material removal. Examples of CAM software include;

• Mastercam

• Fusion 360 (which integrates CAD and CAM)

• ibbsCAM.

How CAD and CAM Work Together in CNC? You can break down the complete CNC precision engineering process into three parts?

1) Design Phase (CAD)

• A designer creates a 3D model of the part using CAD software.

• The model includes dimensions, tolerances, and other specifications.

2) Manufacturing Phase (CAM)

• The CAD model is imported into CAM software.

• The CAM software generates toolpaths and G-code based on the design.

• The G-code is sent to the CNC machine, which follows the instructions to produce the part.

3) CNC Machining

• The CNC machine uses the G-code to control its movements and tools, cutting or shaping the material into the desired form.

Let's look at some of the benefits of Using CAD and CAM in CNC precision engineering.

• Precision: Ensures high accuracy and consistency in manufacturing.

• Efficiency: Reduces material waste and production time.

• Flexibility: Allows for easy design modifications and prototyping.

• Automation: Minimizes manual intervention, reducing human error.

So, to come to consultation, CNC design involves creating digital models (CAD) and generating machine instructions (CAM) to produce parts using CNC machines. Together, CAD and CAM streamline the design-to-production process, enabling efficient and precise manufacturing.

If you are keen to find out some of the key players in the market in Singapore offering CNC precision engineering design, please read our article "Companies in Singapore doing CNC precision engineering tools design". MP Asia Engineering is also a player that offers CNC tooling design services in Singapore. Feel free to visit our CNC Design page for more information.

We hope this article helped. If you have any questions or feedback regarding this article, feel free to contact us at blog@mpasiaengineering.com.

Thank You
MP Asia Engineering Team
Singapore

Author of this article
Nixon Selvakumar
Director
